Specifications
Tuning System
RF Channels
Receiving Systems
Power Requirements
Power Consumption
Chassis
Picture Tube
Audio Output
External Speaker
Connections
Headphone Socket
Aerial Impedance
Component Video
Video / Audio Terminals
Digital Audio input
Video / Audio Input
Monitor Out
Accessories Supplied
Dimensions
Frequency synthesized 100 Position ( 0 to 99 ).
VHF 0to12
UHF 21 to 69
S’1 to S’3
SI to S41
PALB
PALO
HYPER TUNER
1. PALB/G Receotion of Off air broadcasts
2. NTSC 4.43
3. NTSC 3.58
4. PAL 60Hz
Playback from Video Tape Recorders
Playback from Special Video Tape
Recorders and Special Video Disc Players
(Via the AV Sockets) only.
220 ~ 240Voits + 10% 50Hz
TX-S6PW100A
TX-76PW100A & TX-76PW50A
EUR07
228W Max
211WMax 3W Stand-By
3W Stand-By
TX-86PW100A 86cm Viewable (Measured diagonally)
TX-76PW100A & TX-76PW50A 76cm Viewable (Measured diagonally)
Two Way Four Speakers Plus Woofer (10W + 10W + 12W)
TX-86PW100A & TX-76PW100A 10W x Four Speakers (Not supplied)
TX-86PW100A & TX-76PW100A 3.5mm Stereo (Main and Sub)
TX-76PW50A
3.5mm Stereo (Main)
75Q Unbalanced coaxial
TX-86PW100A & TX-76PW100A 1080i and 576P
TX-76PW50A 576P
AV1 IN (Rear) : S-Video, Video, Audio UR Terminals
AV2 IN (Rear)
Video or YIPJP^, Audio UR Terminals
AV3 IN (Front) : S-Video, Video, Audio UR Terminals
AV4 IN (Rear) Video or Y/Pg/P^, Audio UR Terminals
TX-86PW100A & TX-76PW100A coaxial, optical
C: 0.3Vp-p 75ÎÎ S-Video
Video in
Audio in
Video Out
Y: 1.0Vp-p75n
I.OVp-p, 750
Approx. 400mV IkO
1.0Vp-p, 750 Audio Out Approx. 400mV IkO
Remote Control EUR511229
2 Type ‘AA’ Batteries
Instruction Manual TQB4A0152
w
TX-86PW100A 92.6cm
TX-76PW100A & TX-76PW50A 82.7cm
d
65.1cm
53.5cm h
58.4cm
57.9cm Weight
86kg
60kg
Note:
Design and Specifications are subject to change without notice. Weight and Dimensions shown are approximate.
