Most standard Video Cassette Recorders use RCA type video and audio connectors, if your VCR has
different type connectors please refer to the VCR instruction book for details.
) ifo }
1^© ^
^lOIb
V..
(o;
f'-iOTE: A mono VCR can be
connected to this television.
Connect the VCR Audio out
to the Left Audio input on the
television. The sound will
automaticaiiy be directed to
both speakers.
CoiinectiEics S“¥ideo Eauiomenì to the AM input
S'-Video equipmeni uses a 4Pin Mini Din (Male) plug for the video and RCA plugs for the audio. When a?s
S--Video cable is connected to an S-Videc input terminal, the RCA yldeo terminal for that AV position vi/iii
be disconnented.
The audio and video inputs on the television are RCA type connectors.
Connect the Y, PB and PR outputs from the DVD to the
AV4 IN DVD inputs on the television, as shown
beiow. Connect the “AUDIO OUT" to the AV4 IN AUDIO terminals on the television.
Mote: Some DVD players only have an RCA "VIDEO OUT"
' " n DI A v c o terminal. This can be connected to any of the VIDEO
DVD PLAYER Inputs on the television. Connect the “AUDIO OUT”
DVD OUT corresponding AUDIO terminals on the
AV4
VIDEO
DVD
© 0
MONO
i©
AUDIji^
P.V
R
(Г
П
1 C
