INSTALLING THE SPEAKER
• On wall or ceiling
You can install the speaker on a wall or ceiling with a
mounting bracket (not supplied).
® Place the bracket on the enclosure.
CD Screw the eye bolts into the screw holes of the
enclosure by hand.
(D Fix the speaker to a wall or ceiling.
@ Take safety protections mentioned in "Secure the
speaker."
Note: Installers should seek advice on the building
structure and load capacity, if unknown, from
an architect or a structural engineer.
• Secure the Speaker
Use safety wires (not supplied) when hanging the
speaker from a wall or ceiling. This is not a major
means of support but just a safety relief.
® Tighten the eye bolts with washers and bolt nuts
(not supplied) into the screw holes of the enclosure
by hand.
(D Set the direction of the eye bolts to be in the best
position for binding safety wires.
CD Fasten the bolt nuts with wrench.
(3) Bind one end of safety wires to the eye bolts.
(D Secure the other end of safety wires to the
supporting structure of the building.
• Mounting on a stand
1. You can mount the speaker on a speaker stand by
using the stand hole in the enclosure bottom.
2. The stand should have a supporting pipe of o1.5
inches.
3. Take safety protections by placing it in a safety
location, for example.
Set direction (D
Hand
tighten ®
Washer
Eye Bolt
Bolt nut
^ Tighten with wrench CD
Stand hole
(Bottom side)
-
5
-
