ArmCHMËNT (fools-on-Board) ASSEMBUr
A
CAUTION
Do not get the power cord cau^hf under the agitator when using the vacuum
or adacft/nenfs.
The attachments should be conveniently positioned on the side of the cleaner for easy access.
Assemble the hose and attachments to the cleaner as follows:
Place the hose on the tool holder in front of the handle. Grasp the end of the hose and push
It down over the wand, twsting as you push down.
Place the wand in the middle slot of the tool holder, twisting and pushing down over the short
hose to assure a good connection.
Place the other extension wand into the front of the tool holder. Store the dusting brush in
the end of the extension wand.
Place the crevice tool into the rear slot of the tool holder.
Refer to the illustration in the Parts Identification section for correct attachment storage.
ATTACHMENTS
r- Extension
Wands (2)
Dusting—
Brush
Crevice
Tool
3
-
7
-
