A
WARNING
Personal Injury Hazard when Using Attachments.
DO NOT place hands or feet underneath the unit when using the attachment
tools. The agitator assembly begins to revolve rapidly when using attachments.
A
CAimON
When using the attachments, the agitator begins rotating. Do not allow the
cleaner to remain in just one place for a period of time, as the agitator may damage
the floor surface. Avoid placing the cleaner on furniture, the fringed area of rugs,
deep pile carpeting, or carpeted stairs. The ideal position for the cleaner when
using attachments Is for the unit to be on a level area with the handle in the full
upright position.
To remove the wand from the short hose, grasp the top part of the
wand (see ilustration) and twist as you pull up. Once the wand
has been removed it can be used as is, or the other extension wand
can be attached for further reach. The crevice tool can be attached
to the hose or the end of the wand. When attaching the extension
wand or crevice tool, always twist as you push down. If additional
reach is required the dusting brush can be attached to the end of
the crevice tool.
When using the attachments 00 NOT overextend your reach with
the hose as it could tip the cleaner over.
To store attachments, place the hose on the hose holder in front of
the handle. Return the wand to the tool holder, twisting as you push
down to connect it to the short hose cuff. Place the other extension
wand in the tool holder. Store the dusting brush in the end of the
extension wand. Return the crevice tool to the tool holder.
ATTACHMENT USE
CLEANING AREA
ATTACHMENT Furniture*
Between
Cushions* Drapes* Stairs Walls Bare Floors
CREVICE TOOL*^^:^?' X X X X X
DUSTING BRUSH & X X X X
*Always clean attachments before using on fabrics. Attachments used in dirty areas (such as under a
refrigerator) should not be used on other surfaces until they are washed. They could leave marks. (See
the Cleaning Exterior and Attachments section.) Use discretion when using attachments as each type of
cleaning area may vary (forexample, wood vs. carpeted stairs).
-
