Location of Controls
Press here to
open door
Front Control Panel
Video 3 Jacks Located Behind Door
t
;
ch
* ACT»
_________
HEAR "
UT3
CSy Remote Control
Sensor
Quick Reference Control Operation
Power Button - Press to turn television ON or OFF.
Volume Buttons - Press to adjust Sound Level, Audio and Video Menus and to select operating features when
menus are displayed.
Channel Buttons - Press to select programmed channels or to highlight desired features when menus are
displayed.
Action Button - Press to display Main Menu and access or exit On Screen feature and Adjustment Menus.
TV/Video Button - Press to select TV or one of three Video Inputs, for the Main Picture or the PIP frame (when PIP
frame is displayed).
Front/Rear INPUT 3 Selection Switch - Use to set the source of INPUT 3 (INPUT 3 can receive signal from either
the front or the rear jacks)
