Connecting the Telephone Line and Power Supply Cord

1

.

Plug the telephone line cord into the telephone jack supplied by the telephone

company.

2

.

Plug one end of the power supply cord into the receptacle on the rear of the

machine and the other end into an ordinary AC outlet.

Power Supply Cord

RJ11C Telephone Jack

Wall AC Outlet

NOTC

1. To connect a telephone to the machine, break off the protective tab of the TEL connector

on the rear panel.

2. Connecting method of line cord and its type, the type of power supply cord and AC

outlet vary depending on the country.

20
