DTV Mode
Component Video Connection
Jimptiul Mints:
An input signal must be connected to the input
terminals of the monitor, in order to access PC
and DTV mode Icon menus.
Operation
1. Select DTV mode from the TV/PC/DTV menu {located in the TV/PC/DTV Icon).
2. Connect audio/video cables from the Component Video output terminals to the monitor DIGITAL TV INPUT
terminals, as shown.
NOTE:
To operate your Monitor with component video devices properly, refer to the instructions furnished with the
component video device.
Hints:
When there is no signal applied, the Icon menus in
the PC and DTV mode will appear small and
distorted.
This is a normal condition.
TERMINALS ON BACK OF DEVICE
TERMINALS ON BACK OF MONITOR
Q;.^
s
-
video
fi: ® VIDEO
m m
x|
From audloA/ideo
output of device
1^, 11
;pc INPUT
^^1 mX
VIDEO\^
DIGITAL TV
INPUT
To audio/video
input of monitor
audio/video Cable
(not supplied)
