PC Input Connection (Rear)
Operation
1. Select PC (Rear) mode from the TV/PC/DTV menu (located in the TV/PC/DTV Icon).
NOTE:
To select PC (front) press the INPUT button, while PC (rear) is highlighted in the TV/PC/DTV menu.
2. Connect the 15-pin connector cable
(the supplied cable meets FCC standards)
from the computer 15-pin
output terminal to the monitor PC INPUT 15-pin terminal, as shown.
3. Connect an audio/video to Mini-jack cable from the computer Audio output sound source jack to the monitor
PC INPUT AUDIO L & R jacks, as shown.
NOTE:
To operate your Monitor and computer properly, refer to the instructions furnished with the computer.
TERMINALS ON BACK OF MONITOR
To 15-pin Input
terminal of computer
a
o o
S-VIDEO
^ (S) VIDEO
To Audio Input left
and right of monitor
m ^
R P
r
e o
pc INPUT °'f^puT * ^
INPUT 2 INPUT 1
TERMINALS ON BACK OF COMPUTER
ludio/video to Mini-jack Cable
(not supplied)
From Audio output
source of computer
15-pin Connector Cable (TSXX4515-3)
(Use of the supplied cable is recommended)
From 15-pin output
terminal of computer
Helpful Hints:
If the monitor image is scrambled after connecting to a computer,
refer to the troubleshooting section for changing the computer
resolution.
scrambled Image
- 3 7 -
