Specifications
Main Specifications
Model No. CF-47EY6GAAM CF-47FY6GAAM CF-47EY6GJEM CF-47FY6GUEM
CPU Intel® Mobile Pentium®!! Processor
LI Cache Memory: 32 KB L2 (Second) Cache Memory: 256 KB
300PE MHz 333 MHz 300PE MHz 333 MHz
Memory (Expandable to) 64 MB (192 MB Max. )
Video Memory 2.5 MB
LCD Type 13.3" (TFT)
Displayed Colors*^ 256/65536/262144 colors (640 x 480 dots/800 x 600 dots/1024x768 dots)
Hard Disk Drive 6.4 GB*^
Operating System Microsoft® Windows® 95
(FAT32 File System) Microsoft® Windows® 98
(FAT32 File System)
800 X 600 16-color resolution is not supported. If this resolution is selected, the message "There is an error in the display settings" will appear
when you reboot. Start up again, selecting 256 Colors, High Color (16 bits), or True Color (24 bits), following the instructions on the screen.
Besides this phenomenon, you might encounter some unexpected behavior. Do not select 16 color mode in any resolution.
A 16 M color display is achieved by using the dithering function.
1GB = 10^ bytes, 6.2 GB FAT32 partition + 200 MB special partition.
Other Specifications
Keyboard 87 keys
Floppy Disk Drive 720 KB/1.44 MB (two-mode)
CD-ROM Drive 24X speed (MAX)
Slots
PC Card Slots Two Type I or Type II, or one Type III
Allowable current 3.3 V: 400 mA, 5 V: 400 inA,
(total for two slots) 12 V: 120 mA
RAM Module Slot 144-pin, 3.3-V, SO-DIMM, SDRAM
Interface
Parallel Port Dsub 25-pin female
External Display Port Mini Dsub 15-pin female
Serial Port Dsub 9-pin male
Microphone Jack*’ Miniature jack, 3.5 DIA
Headphone Jack Miniature jack, 3.5 DIA
Impedance 32 Q, Output Power 4 mW x 2
Infrared Communication Port IrDA 1,1 compliant, 4 Mbps data transmission speed*^
External Keyboard/Mouse Port Mini DIN 6-pin female
Expansion Bus Connector
Dedicated 100-pin female
USB Port 4-pin
Internal Modem Data: 56 kbps (V.90 & K56flex) FAX: 14.4 kbps
Pointing Device Touch Pad
Speaker Stereo Speaker (built in)
Utility Programs Setup Utility, DMI Viewer, Panasonic Hand Writing, Panasonic Battery Monitor
Sound PC'98 specification Compliant, Maximum 64-voice XG capital Wavetable,
Synthesizer including GM compatibility, Sound Blaster Pro Compatibility
Battery
Battery Pack Lithium Ion 10.8 V, 4.5 Ah
Operating Time*^ Approx. 2.0 hours - 4,5 hours
Charging Time*^ Power On Approx. 5.5 hours
Power Off Approx. 3.0 hours
Clock Battery Coin type lithium battery 3.0 V
AC Adapter*^ Input 100 V - 240 V AC, 50 Hz/60 Hz|Output 15.6 V DC, 3.85 A
Power Consumption Approx. 50 W*^ (maximum when recharging in the ON state)
Physical Dimensions (w x h x d ) 307 mm X 45 mm X 253 mm (12.1 " XI.8 " X 10 ")
Weight Approx. 3.1 kg (Approx. 6.8 lb.)
Use only a monaural condenser microphone.
Separate communications software is necessary.
Varies depending on the usage conditions.
The AC adapter is compatible with power sources up to 240 V AC adapter.
This computer is supplied with a 125 v AC compatible AC cord.
Approx. 1.5 W when the battery pack is fully charged (or not being charged) and the computer is OFF.
