CASING PARTS ASSEMBLY
AJ-D230HP
Ref. No. Fart No. Part Name & Descripl ion
Remarks
Ref. No.
Pari No.
Part Name & Descript ionlV-
Remarks
VMP5356
MECHANISM UNIT FIXING PLATE
2
VYH0257
HANDLE.......
1
4
VGM1386
TOP PLATE
1
5
VMP5366
TOP COVER PLATE
1
6
VGF0701
SCREW CAP
2
7
VMZ2325
TOP PANEL BARRIER
1
8
VMP5354
P.C.BOARD FIXING ANGLE
1
9
VMX2674
P.C.B. HOLDER GUM
1
10
VXA5937
CHASSIS HOLDER FRAME U
1
11
VEP00Y68A
FLEXIBLE CABLE C.B.A.
1
12
VYP6962
FRONT PANEL (1) ASS’Y
1
13
VMP5385
TOP COVER ANGLE
1
14
VMB2923
BLINDER SPRING
1
15
VKF2785
BLINDER PANEL
1
16
VYQ140Ì
CASSETTE GUIDE U
1
17
VGF0706
FLEXIBLE CABLE BARRIER
1
18
VGF0687
SLIDE SW SHEET
2
19
VGU5582
SWITCH KNOB
2
20
VGU5067
VOLUME KNOB
1
21
VMZ2714
AC CABLE BARRIER
1
22
VHJ24AH270M0
FRONT FLAT CABLE
1
23
VMP5369
CONNECTOR ANGLE
1
24
VJH0985
REAR JAa PLATE
1
25
VKU0526
BOTTOM PLATE
1
..51....... XSB26+6FZ.... SCREW
2
52
XSB4+8FCW
SCREW
4
53
XSS4+14FZ
SCREW
2
54
XTN4+10G
SCREW
5
55
XTV3+10GFZ
SCREW
4
56
XTV3+6F
SCREW
11
57
XTV3+6FFR
SCREW
3
58
XTV3+6FFZ
SCREW
9
59
XTV3+8G
SCREW
4
60
XYE4+EF8
SCREW
1
PRT-1
