CASSETTE COMPARTMENT ASSEMBLY AJ-D230HP
Ref. No. Part No. Part NafiKi & Description Remarks
1 VXA6070 CASSETTE COMPARTMENT 1 (M)
2 VUS5865 MAIN SHAFT 1
3 VMA9849 TOP PUTE 1
4 VXA5761 FRONT GUIDE 1 U. 1
5 VMB3075 M GUIDE SPRING 2
6 VHL3191 M GUIDE RIGHT LEVER 1
VML3192 M FRONT GUIDE 2
8 VML3190 M GUIDE LEFT LEVER 1
9 VUL3196 CASSETTE PROTECT PLATE 1
10 VUA9760 L OPENER 1
12 VMB2926 SPRING 1
13 VML2A50 BLINDER PANEL OPENER 1
14 VXA6074 R SIDE PLATE 1 U 1
15 VML3282 SUB RAIL (R) 1
16 VEK7695 SIDE FLEXIBLE 1
17 VXA5766 MAIN RACK R U 1
18 VDG1156 WIPER RACK 2
20 VDB1395 MAIN SHAFT ANGLE 2
21 VDG1155 INTERLOCK GEAR 2
22 VML3193 OPENER DRIVE ARM 1
23 VXL2692 OPENER ANGLE U 1
24 VMB2979 SPRING 1
25 VXA6072 SIDE PLATE L U 1
26 VML3281 SUB RAIL (L) 1
27 VDG1254 INTERMEDIATE GEAR 1
28 VDP1643 WIPER ROLLER 2
29 VDG1237 CLUTCH GEAR 1
30 VMB2980 CLUTCH SPRING 1
31 VDG1236 WORM WHEEL 1
32 VXA5848 MOTOR ANGLE (A) U. 1
33 VXP1797 E.E SLOT IN WORM U. 1
34 VXA5597 MOTOR U. 1 (M)
35 VMA9673 EMARGENCY ANGLE 1
36 VEK7793 MOTOR P.C.BOARD 1
37 VMA9668 HOLDER PUTE 1
38 VEK7715 HOLDER FLEXIBLE U. 1
39 VXA6075 MAIN RACK (L) ASS'Y 1
40 Vlia^A49 WIPER ARM L 1
41 VUB2925 WIPER SPRING L 1
42 VDG1163 WIPER GEAR 2
43 VMB3013 WIPER SPRING R 1
■ VML2A52 WIPER ARM R 1
45 VDP1642 CASSETTE GUIDE ROLLER (2) 2
46 VDP1641 CASSETTE GUIDE ROLLER (1) 2
47 VXA5757 CASSETTE HOLDER 1 U 1
48 VXA5758 ROD L 1
49 VXA5759 ROD R 1
50 VMB3064 SLIDE SPRING 2
51 VML3249 SIDE GUIDE L 1
52 VML3250 SIDE GUIDE R 1
53 VMB3061 SLIDE GUIDE SPRING L 1
54 VUB3062 SLIDE GUIDE SPRING R 1
55 VUS6108 KICK OFF ROD SHAFT 2
56 VML2A54 KICK OFF ARM L 1
57 VWL2A55 KICK OFF ARM R 1
58 Vl©2928 KICK OFF SPRING 2
59 VML2A53 CASSETTE HOLDER ARM 2
60 VMB2927 CASSETTE HOLDER SPRING 2
61 VMX2525 W_ DETECTION ROaER 2
62 VMS5882 CASSETTE HOLDER SHAFT 1
63 VMB3253 M-L DETECTION SPRING 2
64 VMX2559 CASSETTE PRESSURE ROLLER(2) 3
65 VUX2524 aSSETTE PRESSURE ROLLER(l) 1
66 VDG1246 EMARGENCY GEAR 1
67 VMB3109 EMARGENCY SPRING 1
68 VM22661 FRONT GUIDE COVER 1
69 VEE9577 CABLE 1
71 VMX0653 CUT WASHER 4
72 VMX0967 CUT WASHER 14
73 VMX1061 WASHER 4
74 XQN16+A2 SCREW 8
75 XQN2+CF3 SCREW 4
—
..... —
---------------------- -------—
----------- ----.....-.....
Ref.No. Part No. Part Name & Description ^cs Remarks
76 XQN2+A2 SCREW 2
77
78
79
XYN2+C3
XQN2+A3......
LW1D16061
SCREW
SCREW
SCREW
12
..
10
80 XWGV2Y4G WASHER 2
81 XWGV2Z5G WASHER 2
E22 VEP80856A CARRIGE P.C.BOARD 1
‘
------- -------------- --
------ -- —......... ...... - --......................
PRT-9
