other Specifications
Keyboard 87 keys
Floppy Disk Drive 720 fCB/1.44 MB (two-mode)
CD-ROM Drive 24X speed (MAX)
Slots
PC Card Slots Two Type 1 or Type II, or one Type III
Allowable current
(total for two slots)
3.3 V: 400 mA, 5 V: 400 mA
RAM Module Slot*i 144-pin, 3.3-V, SO-DIMM, SDRAM, PC100 Compliant
Interface
Parallel Port Dsub 25-pin female
External Display Port Mini Dsub 15-pin female
Serial Port Dsub 9-pin male
Microphone Jack*^ Miniature jack, 3.5 DIA
Headphone Jack Miniature jack, 3.5 DIA
Impedance 32 O, Output Power 4 mW x 2
External Keyboard/Mouse Port Mini DIN 6-pin female
Expansion Bus Connector Dedicated 100-pin female
USB Port 4-pin X 2
Internal Modem Data: 56 kbps (V.90 & K56flex) FAX;14.4 kbps
Pointing Device Touch Pad
Speaker Stereo Speaker (built in)
Utility Programs Setup Utility, DM! Viewer
Sound HRTF 3D positional audio support 16-bit stereo, WAVE and MIDI playback
Battery
Battery Pack Li-ion 11.1 V, 5.4 Ah
Operating Time*^ Approx. 2.0 hours - 5.0 hours*'*
Charging Time*^ Power On Approx. 5.5 hours
Power Off Approx. 3.0 hours
Clock Battery Coin type lithium battery 3.0 V
AC adaptor*^ Input 100 V - 240 V AC, 50 Hz/60 Hz Output 15.6 V DC, 3.85 A
Power Consumption*® Approx. 45 W*^ / Approx. 70 W (maximum when recharging in the ON state)
Environment
In use Temperature
Humidity
5 ° C to 35 °C*® {41 “F to 95 °F}
30% to 80% RH (No condensation)
Not in use Temperature
Humidity
-20 °C to 60 °C {-4 “F to 140 '*F}
30% to 90% RH (No condensation)
Physical Dimensions (w x h x o) 307 mm X 45 mm X 260 mm {12.1 " X1.8 " X 10.2 "}
Weight Approx. 3.4 kg {Approx. 7.4 ib.}*“
Interface Internal LAN IEEE 802.3 lOBase-T
IEEE 802.3U 100Base-TX
Only a RAM card designed for PC 100 can be added.
Use only a monaural condenser microphone.
Varies depending on the usage conditions.
Only for CF-48M3AAUEM.
The AC adaptor is compatible with power sources up to 240 V AC adaptor.
This computer is supplied with a 125 V AC compatible AC cord.
Approx. 1.5 W when the battery pack is fully charged (or not being charged) and the computer is OFF.
Approx. 3.5 W when the [Wake up from LAN] has been enabled (Model with both an internal modem and an internal LAN port).
Rated power consumption.
Consecutive disk access of the SuperDisk drive between 30'’C and 35'’C {86 “F and 95 °F} for 15 minutes or more may damage the data on
the disk.
