Panel Controls
■ Main unit
The functions indicated by the numbers
(0-
mote control transmitter.
Open Button
(PUSH OPEN)
Memory/Recall Button
(MEMORY/RECALL)
Repeat Button 0
(REPEAT)
Skip/Search Buttons
( - S K I P / — S E A R C H ►►!)
Stop/Operation Off Button 0
(■ STOP/OPR OFF)
Piay/Pause Button 0
(► II PLAY/PAUSE)
Line Out Jack
(LINE OUT)
DC IN Jack (DC IN 4.5 V <0^^^ )
Disc Holder
Battery
Compartment
Cover [bottom]
Headphones Jack ( Q )
ASC/S-XBS Selector
(ASC/S-XBS)
Phones Level Control (VOLUME)
----------------------Live Switch (LIVE)
When the AC adaptor or the car adaptor is
used, the backlights of the Stop/Operation
Off Button and the Play/Pause Button are
illuminate.
Lock Switch (LOCK)
Prevents accidental
opening of the disc holder.
Remote Sensor Jack
(REMOTE SENSOR)
Play Mode Selector
(PLAY MODE)
Hold Switch (HOLD)
Note:
Before operating the front panel button, be
sure to release the hold and the lock state.
>
, LC
)CK
HOLD
--------- 1
