Table 2, 3 and 4 are sample settings for a Sample Network.
Table 2: Sample Parameter and Abbreviated Dialling Number Table for New York
Telephone Number
Network Address
Relay Address
212 111 1234
1000
10
One-Touch/
ABBR No.
Station Name
Telephone
Number
Relay
Address
Relay Station
Yes/No
Network
Address
One Station
XMT
01 London 44 71 111 1234 20 Yes 2000 Direct
02 Stockholm 46 8 111 1234 20 No 2001 Direct
03 Berlin 49 611 111 1234 20 No 2002 Direct
04 Rome 39 6 111 1234 20 No 2003 Direct
05 Singapore 65 111 1234 30 Yes 3000 Direct
06 Tokyo 81 33 111 1234 30 No 3001 Direct
07 Hong Kong 852 4 111 1234 30 No 3002 Direct
08 Sydney 61 2 111 1234 30 No 3003 Direct
09 Wellington 64 4 111 1234 30 No 3004 Direct
!
Table 3: Sample Parameter and Abbreviated Dialling Number Table for London
Telephone Number
Network Address
Relay Address
71 111 1234
2000
20
One-Touch/
ABBR No.
Station Name
Telephone
Number
Relay
Address
Relay Station
Yes/No
Network
Address One Station
XMT
01 Stockholm 46 8 111 1234 20 No 2001 Direct
02 Berlin 49 611 111 1234 20 No 2002 Direct
03 Rome 39 6 111 1234 20 No 2003 Direct
04 New York 1 212 111 1234 10 No 1000 Direct
05 Singapore 65 111 1234 30 Yes 3000 Direct
06 Tokyo 81 33 111 1234 30 No 3001 Direct
07 Hong Kong 852 4 111 1234 30 No 3002 Direct
08 Sydney 61 2 111 1234 30 No 3003 Direct
09 Wellington 64 4 111 1234 30 No 3004 Direct
Table 4: Sample Parameter and Abbreviated Dialling Number Table for Singapore
Telephone Number
Network Address
Relay Address
65 111 1234
3000
30
One-Touch/
ABBR No.
Station Name
Telephone
Number
Relay
Address
Relay Station
Yes/No
Network
Address
One Station
XMT
01 New York 1 212 111 1234 10 No 1000 Direct
02 London 44 71 111 1234 20 Yes 2000 Direct
03 Stockholm 46 8 111 1234 20 No 2001 Direct
04 Berlin 49 611 111 1234 20 No 2002 Direct
05 Rome 39 6 111 1234 20 No 2003 Direct
06 Tokyo 81 33 111 1234 30 No 3001 Direct
07 Hong Kong 852 4 111 1234 30 No 3002 Direct
08 Sydney 61 2 111 1234 30 No 3003 Direct
09 Wellington 64 4 111 1234 30 No 3004 Direct
103
