37
Radiance Direct Vent /Natural Vent Gas Heater
20004188
Radiance Direct Vent/Natural Vent Gas Heater (RDVOD)
Models: 3225 thru 3232, 3350 thru 3354, 3360 thru 3369, 3390 thru 3399 (continued)
Ref. Description RDVOD
8. Glass, GFP Firebox 1601290
9. Ceramic Handle w/Insert LFTR 0004345
10a. Valve RN Honeywell VS8420E 2038 10001782
10b. Valve RP Honeywell VS8420E 2020 10001759
11a. Valve Gas Honeywell Convertible RFN RV8310E 20003719
11b. Valve Gas Honeywell Convertible RFP RV8310E 20003720
12a. Pilot Assembly 3Way N/DV RN 0.199.706 10002264
Pilot Assembly 3Way N/DV RP 0.199.703 10002265
12b. PIlot PSE - NA175 20001115
Pilot PSE - LP175 20001116
12c. Pilot Assembly 3Way DV/RFN CS3003A2009 20002266
Pilot Assembly 3Way DV/RFP CS3003A2017 20002268
13. Thermocouple 24” 53373
7531137
14. Electrode Ignitor w/ Cable SIT24 10001297
15. Pilot Top Convertible 10002266
16. Thermopile 18” RS 51827
7533113
17. Nut Electrode SIT #0.974.144 57886
18. Tubing Pilot w/ Fitting 1/8 x 24” 10001296
19. Thermopile PSE for RF Pilots 20002400
20a. Pilot Orifice #62 - NG Top Convertible 10002268
20b. Pilot Orifice #35 - LP Top Convertible 10002269
21a. PIlot Orifice PSE RFN 20000908
21b. PIlot Orifice PSE RFP 20000907
22. Antennae, Honeywell 395783-1 20003561
23. Front II, RDVOD Refer to Enamel Parts Chart Page 38
24. Door Left - RDVOD Refer to Enamel Parts Chart Page 38
25. Door Right - RDVOD Refer to Enamel Parts Chart Page 38
26. Control Door, RDVOD Refer to Enamel Parts Chart Page 38
27. Burner Housing Assembly 20003526
28. Log Rear Bracket 20003577
29a. Orifice Hood (.043) - Front - LP 20004587
29b. Orifice Hood (.067”) - Front - NG 30000449
29c. Orifice Hood (.055”) - Rear - LP 20000130
29d. Orifice Hood (.098” ) - Rear - NG 20004263
30. Gasket Base Pan 20004287
31. Gasket Inner Base Pan 20004286
32. Bracket, Right Log 20005259
33. Bracket, Left Log 20005258
34. Grate Decorative Burner 20003536
35. Wire w/Straight Term 2 End 50” 10002582
36. Transmitter Honeywell RF 20002047
37. Sensor 2450 CMG-8184-0032 10002013
38. Damper Steel Handle/Screw 30002720
39. Latch, Front Door - RDV 30001249
41. Glass Frame Assembly - RDV40 5003075
44. Washer, Flat 1/4 - Blk. 266 x .629.064 1202473
45. CS, Hex Hd 1/4-20 x 5/8” - Blk 1201372
46. Left End Refer to Enamel Parts Chart Page 38
47. Right End Refer to Enamel Parts Chart Page 38
48. Leg Refer to Enamel Parts Chart Page 38
49. Control Door Handle Assembly 30002730
50. Gasket, HE Door 1203687
51. Top Refer to Enamel Parts Chart Page 38
52. FK26 Fan Subassembly (RF Only) 30000879
53. Grille, RDV40 1301195
54. Screen, Top RDV40 1601970
