EdgeAccess Universal Chassis System
L312 Ethernet Media Converters 3-2
Table 2. CLIM Status LED
Color Description
Off No power
Green Normal operation
Amber System self-test
Red CLIM self test failure
The CLIM front panel has two full-duplex, fixed-rate interface ports:
• The User Port receives and transmits the 10Base-T Ethernet signal on UTP cable.
• The Extension Port receives and transmits the Ethernet signal over multimode or single mode
fiber at various wavelengths:
•
Multimode 850nm
•
Single mode 1310 - 1550nm
The LNK/Rx and Tx LEDs near the User and Extension port connectors show the status for those
ports. Table 3 shows the LED states for various port conditions.
Table 3. CLIM LNK/RX and TX LEDs
LED Status Description
Off No transmission activity
Green blinking Transmission activity
Amber System self-test
Tx
(User Port)
Red Transmission disabled due to LLF
Off No link
Green Link Established
Green blinking Receiving activity
LNK/Rx
(User Port)
Amber System self-test
Off No transmission activity
Green blinking Transmission activity
Amber System self-test
Tx
(Extension Port)
Red Transmission disabled due to LLF or LLE
Off No link
Green Link Established
Green Blinking Receiving activity
LNK/Rx
(Extension Port)
Amber System self-test
