Beckett SDC 12V - Manual (Page 2)

2
Contents
Prepare Before Installing ............................................ 3
Hazard Defi nitions .............................................................3
General Specifi cations .......................................................3
Notice Special Requirements.............................................3
General Information .................................................... 4
A. Equipment Located in Confi ned Space .........................4
B. Exhaust Fans and Other Air-Using Devices. .................4
C. Clearances to Burner and Equipment ...........................4
D. Exhausting Hazardous Fumes ......................................4
Nozzle Assembly Maintenance .................................. 4
A. Replace the Burner Nozzle............................................4
B. Check/Adjust Electrodes ...............................................5
C. Igniter Maintenance .......................................................6
D. Servicing Nozzle Line Assembly ...................................6
E. Check/Adjust “Z” Dimension ..........................................6
Fuel Supply .................................................................. 7
A. Connect Fuel Lines........................................................7
B. Fuel Supply Level with or Above Burner........................7
C. Fuel Supply Below Level of Burner ...............................7
D. Fuel Line Replacement (Remote Tank Only) ................7
E. Fuel Line Valve and Filter .............................................7
Burner Wiring ............................................................... 7
A. Burner installed on equipment .......................................7
B. Burner Replacement......................................................7
Drive Component Maintenance .................................. 9
A. Motor, Blower Wheel, and Coupling Replacement ........9
B. Pump Maintenance......................................................10
C. Solenoid Valve Testing ................................................10
Start Up Burner & Set Combustion .......................... 10
A. Basic Burner Operation ...............................................10
B. Combustion Set-up ...................................................... 11
C. Set Combustion with Instruments................................ 11
Maintain & Service Burner ........................................ 12
A. Owner’s Information ....................................................12
B. Owner Service and Maintenance ...............................12
Extended Down Time .......................................................12
Regular Service/Maintenance ..........................................12
Troubleshooting ........................................................ 13
Replacement Parts .................................................... 15
Limited Warranty Information .................................. 16
Hazard Defi nitions
Within the boundaries of the hazard warning, there will
be information presented describing consequences if the
warning is not heeded and instructions on how to avoid
the hazard.
Indicates a hazardous situation,
which, if not avoided, will result
in death or serious injury.
Indicates a hazardous situation,
which, if not avoided, could
result in death or serious injury.
Indicates a hazardous situation,
which, if not avoided, could
result in minor or moderate injury.
Intended to bring special attention
to information, but not related to
personal injury or property damage.
