THINGS NEED BESIDES THE KIT
RADIO CONTROL UNIT
12V Battery for Starter Box
(must have)
Glow Plug Heat with Battery & Charger
# 10227....$$19.95
(please note OFNA Glow Heats available)
AA Batteries ( 12 pcs ) for radio
Note: Careful read the instruction manual of your
2 channel radio controller before using.
Radio must be set at neutral position
before installing in the kit.
SEQUENCE TO SET NEUTRAL
Note: The engine may not include in kit.
Glow Fuel
20%
Install AA batteries in Radio.
Extend the antenna.(Transmitter)
Install batteries into Car receiver .
After installing the battery, connect the
battery box.
Extend the antenna. (Receiver)
Set the trim-leved at center.
Turn on the switch. (Transmitter)
Turn on the switch. (Receiver)
Make sure the servos are in command.
When the operation stick is in neutral,
servo horns must be in neutral as
will.
*Adjustment can be made by re-
installing the servo horn.
Turn off the switch. (Receiver)
Turn off the switch. (Transmitter)
Retract the antenna. (Transmitter)
11 11
12
13
REQUIRED FOR OPERATION
Bottle’s with spout
# 10160 - large 500cc
# 10161 - large 500 ccAuto Stop
# 10162 - small 250cc
# 10164 - CNC spout 500CC
INCLUDED WITH KIT
Shock Oil
1.5mm Allen Wrench
2.5mm Allen Wrench
Grease Box
SUITABLE SERVO SIZE
29mm - 42mm
15mm - 21mm
36mm-41mm
3.5 cc (21 Class) ENGINE
REAR EXHAUST
Off-Road Starter Box
# 10250 - 1/8 scale Starter Box
# 10253 - 1/8 scale Starter Box w/ Panel
Add-on
# 92571 - Power Panel Glow Heater
# 92572 - Cable for Glow Plug
TOOLS NOT INCLUDED IN KIT
Phillips Type Screw Drivers ( L )
Phillips Type Screw Drivers ( S )
Needle Nose Pliers
Cutter
Curved Scissors
Knife
Instant Cement
Cross Wrench
#17109 $3.95
Glow Plug & 17MM Cross Wrench
#10801 $6.95
Masking Tape
Paints
Grease
Brush
More Optional Parts . . .
#10211 NiHm Battery Flat
Pack .. $29.95
# 10214 NiHm Battery Pack
Charger.. $7.95
OFNA/Picoo Glow Plug ..
$4.95
