Assembly of the front and rear shock spring – OFNA Racing Ultra GTP2e User Manual

Page 19

background image

44

45

16

43

ASSEMBLY OF THE FRONT SHOCK ABSORBER

ASSEMBLY OF THE REAR SHOCK ABSORBER

94041
3mm
Nylon Nut

.....x2

94007
3x20mm
Hex Screw

.....x2

3mm

3x25mm

40531

94040
3x8mm

3x20mm

3mm

40531

3x8mm

3x20mm

3x25mm

90018
3x25mm
Cap Screw

.....x2

94041
3mm
Nylon Nut

.....x2

94007
3x20mm
Hex Screw

.....x2

90018
3x25mm
Cap Screw

.....x2

ASSEMBLY OF THE FRONT AND REAR SHOCK SPRING

Assembly for both right and left side.

Assembly for both right and left side.

40643

40643

30274

30275

* Assemble 2 Sets for Front

* Assemble 2 Sets for Rear

Do Not
Over Tighten

Do Not
Over Tighten
