Page 18

ASSEMBLY OF THE REAR SHOCKS

.....x2

.....x4

.....x2

.....x4

.....x2

40090
2mm Washer

40090
1mm Washer

40090

2.6x6mm Washer

2.5mm Nylon Nut

40643
Shock Plastic
Ball End
(Short)

40090

40090
1mm

40090
2mm

40638

2.5mm

2.6x6mm
Washer

40054

1. Pull down piston and
pour oil into shock
cylinder.
2.To remove air bubbles
by slowly moving
piston up and down.

30403
6mm Ball End

*Fill the shocks
with oil approx 90%.

40090
3.5mm O-Ring

3. Pull down piston,
attach pressure top
and shock oil
overflow with tissue
paper.

40632

40637

40635

30403

Step 1

Step 2

40643

40633

40640

CORRECT SHOCK ASSEMBLY

Carefully screw the
shock shaft into the
bottom of the plastic
ball and until the
distance between the
ballend and the shock
body is 32mm for the
front.
N.B. Do not over tighten
as the plastic will strip.

ASSEMBLY OF THE REAR SHOCKS

* Make 2 for Shocks for rear.

*Fit the o-ringinto groove before
assembly.

40090

40643
Shock Plastic
Ball End
(Short)

40090

40090
1mm

40090
2mm

40638

2.5mm

2.6x6mm
Washer

40736

1. Pull down piston and
pour oil into shock
cylinder.
2.To remove air bubbles
by slowly moving
piston up and down.

*Fill the shocks
with oil approx 90%.

3. Pull down piston,
attach pressure top
and shock oil
overflow with tissue
paper.

40737

40637

40635

30403

Step 1

Step 2

40634

40636

40643

40633

40640

CORRECT SHOCK ASSEMBLY

Carefully screw the
shock shaft into the
bottom of the plastic
ball and until the
distance between the
ballend and the shock
body is 15mm for the
front.
N.B. Do not over tighten
as the plastic will strip.

.....x2

.....x4

.....x2

.....x4

.....x2

40090
2mm Washer

40090
1mm Washer

2.6x6mm Washer

2.5mm Nylon Nut

30403
6mm Ball End

40090
3.5mm O-Ring

* Make 2 for Shocks for front.

*Fit the o-ringinto groove before
assembly.

40634

40636

BATTERY INSTALL

If use hard case battery , make a hole as picture shown.

8mm

15mm

Follow the manual instruction provided by ESC
manufacturer to install the wire.
