19

94041
3X8mm
Washer

3mm
Nylon Nut

94007
3X20m m
Hex Screw

Step 1

47

ASSEMBLY OF THE TIRES AND WHEELS

Step 2

Step 3

Apply instant glue into the groove of the wheel.

46

ASSEMBLY OF THE REAR SHOCK ABSORBER

94041
3mm .......x2
Nylon Nut

94007
3X20m m .......

.x2

Hex Screw

Assembly both right and left side.

I

S

A

T

N

T

N

G

L

U

E

Inner Sponge

80007
Tires

86101
Whee l

48

ASSEMBLY TIRE ONTO FRONT KNUCKLE AND REAR HUB .

15072
Wheel Nut

15072
Wheel Nut

Tire and whee

l

assem bly.

10239
Ca Glue
