ASSEMBLY OF THE MANIFOLD AND MUFFLER

ASSEMBLY OF THE CLUTCH AND ENGINE MOUNT

10098
SG Clutch Nut

Step 1

Step 3

Step 4

Step 2

Step 1

Step 2

10120
Manifold
Spring

10069
1/8
Silico ne Seal

31991
Manifo ld

31992
Muffle r
(9.5mm Exhau st)

10184
Silicon e Tube

Nylon Straps
(Midd le)

30481
3X16m m
Cap Screw

10099
3X10m m
Cap Screw

10099
3X8mm
Washer

10099
5X9X0 .3mm
Washer

34110
5x10x 4mm
Ball Bearin

g

34110
5X10X 4mm
Ball Bearin

g

10399
13T
Clutch Bell

10040
3Pin
Flywh eel

10330
7mm
Tapper Corn

10009
Clutch Shoes

10101
Clutch Spring

10099
3X10m m ........

X1

Cap Screw

30481
3X16m m .......

X4

Cap Screw

40674
Engine Moun t

40573
3 Pin Flywh

eel

(35mm )

10091
Pilot Shaft

Threaded
CrankShaft

* Only use this #174D pilot shaft for threaded crank
shaft engine.

10330
Tapper Corn
