16 ASSEMBLY OF THE REAR ARMS HOLDER
7
94003
3X10mm
Hex Screw
40531
Shock Ball End
Post
40531
Shock Ball End
Post
90018
3X25mm
Cap Screw
90018
3X25mm
Cap Screw
40026
Rear Shock Stay
94004
3X12mm
Hex Screw
94036
5X4mm
Set Screw
36730
Cap Joint
40025
Rear Lower
Arm Holder
94011
4X15mm
Hex Screw
94030
4X45mm
Flat Head
Hex Screw
94003
3X10mm
Hex Screw
40015
Rear Arm
Holder
40027
Win Stay
Mount
94009
4X10mm
Hex Screw
40027
Rear Body
Post
94003
3X10
Flat Head
Hex Screw
40137
Body Post
Plastic
94036
5X4mm .......X1
Set Screw
94003
3X10mm .......X1
Hex Screw
94011
4X15mm .......X2
Hex Screw
94009
4X10mm .......X2
Hex Screw
94030
4X45mm
Flat Head
Hex Screw .......X2
ASSEMBLY OF THE REAR SHOCK STAY 17
94003
3X10mm .......X1
Hex Screw
94004
3X12mm .......X2
Hex Screw
90018
3X25mm .......X2
Cap Screw
94019
3X10 .......X2
Flat Head
Hex Screw
Sc
re
w
C e
e m
n t
S c re
w
C m
n e t e
w re c S
C em
en t
