background image

Manual-7

SSE 35 Features & Specifications

Parameter

Specification

Limit

Units

Conditions/Comments

LCR Equalizers: Bands

(11) 2/3-Octave ISO Spacing

From 160 Hz to 16 kHz

..........Type

Constant-Q

3% Accuracy to center frequency

..........Travel

20

mm

Positive grounded center detent

..........Range

±6

0.25

dB

LR Subwoofer Equalizers:

Left & Right Subwoofers

..........Bands

(7) 1/3-Octave ISO Spacing

From 25 Hz to 100 Hz

..........Type

Constant-Q

3% Accuracy to center frequency

..........Travel

20

mm

Positive grounded center detent

..........Range

±6

0.25

dB

Subwoofer LP Crossovers:
..........Type

4th-Order Butterworth

Left & Right low pass filters

..........Frequency

80 or 125

Hz

Slide switch selectable

..........Slopes

24 dB/Octave

4th-order

Inputs: Type

Active Unbalanced

RCA phono connectors

..........Impedance

10k

1%

Ohms

..........Maximum Level

+20

1

dBu

11 Volts peak

Outputs: Type

Active Unbalanced

RCA phono connectors

..........Impedance

100

1%

Ohms

..........Maximum Level

+20

1

dBu

11 Volts peak into 2k ohms or greater

Frequency Response

20-20 kHz

±1

dB

Left, Right & Center

THD+Noise

0.001

typ

%

1 kHz, +4 dBu

0.015

.005

%

20-20 kHz, +4 dBu

SMPTE IM

0.01

.005

%

60 Hz / 7 kHz, 4:1, +4 dBu

Signal-to-Noise

100

1

dB

re +4 dBu; 20 kHz BW; flat

Dynamic Range

116

1

dB

Max out / noise floor (+20 dBu/-96 dBu)

Channel Separation

80

typ

dB

1 kHz

Unit: Agency Listing
..........120 VAC model

Class 2 Equipment

National Electrical Code

UL 813 Exempt

Class 2

CSA Exempt

Class 2

..........230 VAC model

VDE, SELV

Safety Extra Low Voltage

CE-EMC

EMC directive 89/336/EEC

CE-Safety Exempt

Per article 1 of LVD 73/23/EEC

Power Supply: Agency Listing

Model RS 1

..........120 VAC model

UL Listed

File no. E88261

CSA Certified

File no. LR58948

..........230 VAC model

CE-EMC

EMC directive 89/336/EEC

CE-Safety

LV directive 73/23/EEC

Power Supply: Input

18 VAC w/center tap

10%

Vrms

6-pin mod plug

..........Current

750

max

mA

RMS current from remote supply

Unit: Size

1.75"H x 17.3"W x 8"D

w/o Rack Ears

(4.4 cm x 43.9 cm x 20.3 cm)

..........Weight

5 lb

(2.3 kg)

Shipping: Size

7" x 22" x 13"

(18 cm x 56 cm x 33 cm)

..........Weight

9 lb

(4.1 kg)

Note: 0 dBu=0.775 Vrms
