3

RANE MP 4

FOR

SERATO SCRATCH LIVE •

QUICK START

1.9.1

Cd PLAyER CoNNECTIoN

1. IN 1 and IN 2 inputs on the back of the MP

4. Push the PHONO / LINE switches out for
LINE.

2. Connect the USB cable from the MP 4 to

your computer as described in the previous
section. Note: On some Windows machines,
each USB port is treated separately, requiring
a separate driver install for each USB port.
See DRIVER UPDATE TOOL on the previous
page.

USB MIdI CoNTRoLLER CoNNECTIoN

Scratch

Live

version currently has native support

for the following 3rd party controllers:
• Denon DN-HC4500
• Denon DN-HD2500
• Numark DMC2
• Numark ICDX
• Pioneer CDJ-400
• Pioneer MEP-7000
These controllers use MIDI to operate transport
controls and “scratch” with Scratch

Live

. These

are plug and play, and can automatically control
Scratch

Live

with no MIDI assigment necessary.

Connection requires two USB cables from your
computer: one to the MP 4, and another to the
USB controller. Installation and features will vary.
Search for support instruction articles with your
model number at www.scratchlive.net.

CoNNECTIoNS

MADE IN U.S.A.

RANE CORP.

RIGHT

LEFT

RIGHT

RIGHT

LEFT

LEFT

LEVEL

R

L

PHONO

LINE

PHONO
GROUND

MIC TO

USB RECORD

MP 4

HOUSE

AUX

IN 2

IN 1

MIC

ACN 001 345 482

BALANCED OUTPUTS: TIP = (+), RING = (–), SLEEVE = SIGNAL GROUND

BALANCED INPUT

PHONO

LINE

YES

NO

USB

100-240V

50/60 Hz 7 WATTS

FOR CONTINUED

GROUNDING PROTECTION

DO NOT REMOVE SCREW

COMMERCIAL AUDIO

EQUIPMENT 24TJ

R

Two CD players or

Two Turntables

or One of Each.

USB MIDI DJ Controller

U

U

U

S

S

S

B

B

B

M

M

M

I

I

I

D

D

D

I

I

I

D

D

D

J

J

J

C

C

C

o

o

n

n

t

t

r

r

o

o

l

l

l

l

l

l

e

er

TURNTABLE CoNNECTIoN

1. Connect your turntables to the IN 1 and IN 2

inputs on the back of the MP 4. Push the
PHONO / LINE switches in for PHONO.

2. Connect the turntable ground wires to the

ground post of your mixer.

3. Connect the USB cable from the MP 4 to

your computer as described in the previous
section. Note: On some Windows machines,
each USB port is treated separately, requiring
a separate driver install for each USB port.
See DRIVER UPDATE TOOL on the previous
page.
