MP 2016a Mixer Port
This is the required socket to connect the XP 2016a to the
MP 2016a, using the ribbon cable supplied with the XP 2016a.
If a ribbon longer that that supplied with the XP 2016a is used,
crosstalk may increase, and immunity to RF, magnetic and con-
ducted interference may be compromised. So don’t do it!
POWER
This power jack receives the cable from the RS 1 power sup-
ply shipped with the unit. The chassis ground screw located just
above the jack is intended for earth grounding the chassis (see
the Chassis Grounding note on page Manual-4).
XP 2016a Ribbon Connections: (PIN 1 marked Ñ)
1) GND
2) GND
3) MIX RIGHT OUT
4) MIX LEFT OUT
5) GND
6) METER LEFT IN
7) METER RIGHT IN
8) GND
9) CH 6R IN
10) CH 6L IN
11) GND
12) CH 5R IN
13) CH 5L IN
14) GND
15) CH 4R IN
16) CH 4L IN
17) GND
18) CH 3R IN
19) CH 3L IN
20) GND
21) CH 2R IN
22) CH 2L IN
23) XP 2016 ENABLE (GND)
24) CH 1R IN
25) CH 1L IN
26) GND
Fader Cleaning
With heavy use in harsh environments, the faders may need
lubrication. This treatment extends longevity and can make used
faders as good as new. The fader assembly must be removed from
the XP 2016a for proper cleaning. We recommend any of the
following cleaning solutions:
Caig DeoxIT FaderLube F100 spray lubricant (www.caig.com)
Caig DeoxIT FaderLube F5 spray cleaner (www.caig.com)
CRC 2-26 (www.crcindustries.com)
Order DeoxIT® from:
CAIG Laboratories, Inc.
12200 Thatcher Ct.
Poway, CA 92064
Phone 858-486-8388
Fax 858-486-8398
Web www.caig.com
CLEANING INSTRUCTIONS
A. Fader assembly removal
1. Remove (2) 3mm screws.
2. Draw fader assembly out through hole.
3. Remove ribbon cable.
B. Fader cleaning
1. Hold the fader assembly away from the mixer.
2. Position the fader at mid-travel.
3. Spray cleaner/lubricant into both ends of the fader.
4. Move the fader over its full travel back and forth a few times.
5. Shake excess fluid from the fader assembly.
6. Wipe off excess fluid.
CLASS 2 EQUIPMENT
750mA
POWER MP 2016a
MIXER
ACN 001 345 482
U.S. PATENT PENDING
MADE IN U.S.A.
RANE CORP.
XP 2016a
