MM 8z APPLICATIONS
Two Pre/Post Crossfader ASSIGN switches add to the
flexibility of the MM 8z. By placing these in the POST
position, the Crossfader is bypassed, allowing the Source 1 or
4 to be a separate mixer or other device, while still using the
MM 8z's Crossfader with Sources 2 and 3. This powerful new
feature greatly increases the flexibility of the MM 8z, making
it one of the most capable mixers in it’s price range.
It is now possible to have a pair of booth turntables on
Source 2 and B Mix Source 3, each sent to the Crossfader,
IN 1
LINE 2
POST
IN 2
PHONO 3
(PRE)
IN 3
PHONO 5
(PRE)
IN 4
LINE 8
POST
MM 8z
TTM 54i
MM 8z
Wireless Mic
Drum Machine
IN 1
LINE 2
POST
IN 2
PHONO 3
(PRE)
IN 3
PHONO 5
(PRE)
IN 4
LINE 8
POST
TTM 54i TTM 54i
OR
while having the output of a 2 nd Performance Mixer connected
to Source 1 and summed post Crossfader. Source 4 could be
summed Pre-crossfader for use with a 3
rd booth turntable, or
Post-crossfader to allow use of a 3rd mixer, a wireless
microphone, a drum machine, etc... you get the idea. The
examples shown below illustrate some of the many possibili-
ties. Any of the turntables can be replaced with CD players by
switching the Phono Input to Line level.
