Pressure and Differential
Pressure Switches
G- and L-Series pressure, differen-
tial pressure and vacuum switches
use two different actuators depend-
ing on setpoint requirements. For
setpoints between 2 and 3000 psi,
the simple, rugged diaphragm-
sealed piston actuator is used. This
design features high reliability and
a choice of actuator seal materials
for virtually every application. An
optional welded design is also
available for setpoints up to 1000
psi for maximum reliability. This
design is available in 316 SS or
Monel. Differential pressure models
use a unique dual-diaphragm-
sealed piston design that features
very high static operating pressures
and small size.
For setpoints between 4.5 and 150
inches of H
2
O, a large diaphragm is
used for increased sensitivity in
both pressure and differential
pressure designs with good choice
of materials of construction.
All standard models feature
±
1
percent of range setpoint repeat-
ability and a minimum of 400
percent of range proof pressures.
These standard designs perform
well in applications where shock
and vibration could be a problem
and may be used with Ashcroft
diaphragm seals in extreme
services such as slurries or abra-
sive process fluids.
DIFFERENTIAL PRESSURE SWITCHES
PRESSURE/VACUUM SWITCHES
Overpressure Approximate Deadband (Buna-N Diaphragm) (2)
Ratings
LPA-GPA (3) LPS-GPS (4) LPD-GPD (4)
Proof psi
Minimum Switch Element
Nominal Range (1)
Burst psi J, H G J, H K, F P GG JJ, HH KK,FF PP
Vacuum
-30" Hg -760mm Hg 250 400 6-24 2.5-4 4-6 1-2 1-2.5 3-5.5 4-6.5 1-2 1-2.5
Compound
-30" Hg/ -760mm Hg/ 250 400 6-24 2.5-4 4-6 1-2 1-2.5 3-5.5 4-6.5 1-2 1-2.5
15 psi 1.0 kg/cm 2 3-12 1-2.5 1-3.5 0.5-1.5 0.5-2 1.5-3.5 1.5-4 1-2 1-2
Pressure
30" H
2
O 750mm H
2
O 20 35 4.0-27 1.5-3.5 2.0-4.0 0.5-1.0 0.7-2.0 2.1-4.9 2.8-5.6 0.7-1.4 0.7-2.8
60" H
2
O 1500mm H
2
O 20 35 5.0-54 1.5-4. 2.5-5.0 0.5-1.4 1.0-2.5 3-5.6 3.5-7.0 0.7-2.0 2-3.5
100" H
2
O 2500mm H
2
O 20 35 8.5-90 2.0-5.5 4.0-8.5 1.0-2.0 1.4-3.0 4-7.7 5.6-11.7 1.4-2.8 2-4.2
150" H
2
O 3750mm H
2
O 20 35 18-135 5.0-11 10-18 1.5-3.0 2.0-6.0 7.0-16 14-25.1 2.1-4.2 5-9.2
15 psi 1 kg/cm 2 500 1000 2.5-13 1.0-1.5 1.0-2.5 0.5-1.0 0.75-1.5 1.4-2.1 1.4-3.5 .7-1.4 1-1.4
30 psi 2 kg/cm 2 500 1500 3.0-27 1.0-2.8 1.0-3.2 .75-1.5 1-1.8 1.4-5 3-6 1-2.1 1.4-2.5
60 psi 4 kg/cm 2 500 1500 5.0-54 2.0-4.0 2.0-4.5 1.0-2.0 1.0-2.5 3-7 4-8 1.4-2.8 1.4-3.5
100 psi 7 kg/cm 2 1000 3000 10-90 3-6 5.0-10 1.0-2.5 1.4-3.2 7-12 7.0-14 1.4-3.5 3-7
200 psi 14 kg/cm 2 1000 3000 18-180 7-14 10-18 1.0-4.0 5.0-8.0 10-23 14-25 1.4-5.6 7.0-11.2
400 psi 28 kg/cm 2 2400 3000 45-360 16-30 16-45 4.0-8.0 5.0-15 22-42 22-63 5.6-11.2 7.0-21
600 psi 42 kg/cm 2 2400 3000 75-540 16-50 20-75 5.0-15 6.0-25 22-70 28-105 7.0-21 8.0-35
1000 psi 70 kg/cm 2 12,000 14,000 160-900 75-130 50-160 7.0-30 10-85 70-180 70-223 10-42 14-119
2000 psi 140 kg/cm 2 12,000 14,000 350-1800 150-200 150-350 20-50 25-110 209-279 209-488 28-70 35-154
3000 psi 210 kg/cm 2 12,000 14,000 400-2600 180-250 180-400 30-70 30-190 251-349 251-558 42-98 42-226
Overpressure Approximate Deadband (Buna-N Diaphragm) (5)(2)
Ratings
LDA-GDA (3) LDS-GDS (4) LDD-GDD (4)
Static Working
Proof psi
Switch Element
Nominal Range (1)
Pressure psi J, H G J, H K, F P GG JJ, HH KK,FF PP
Pressure
30" H
2
O 750mmH
2
O 5.4 21.6 4.0-27 1.5-3.5 2.0-4.0 0.5-1.0 0.7-2.0 2.1-4.9 2.8-5.6 0.7-1.4 0.7-2.8
60" H
2
O 1500mmH
2
O 5.4 21.6 5.0-54 1.5-4.0 2.5-5.0 0.5-1.4 1.0-2.5 2.5-6 3.5-7.0 0.7-2.0 2-3.5
100" H
2
O 2500mmH
2
O 5.4 21.6 8.5-90 4.0-5.5 4.0-8.5 1.0-2.0 1.4-3.0 5.6-7.7 5.6-11.9 1.4-2.8 2-4.2
150" H
2
O 3750mmH
2
O 5.4 21.6 18-135 5.0-11 10-18 1.5-3.0 2.0-6.0 7.0-15.4 14-25.2 2.1-4.2 2.8-8.4
30 psi 2 kg/cm 2 500 2000 3.0-27 1.0-2.5 1.0-3.0 1.0-1.5 1.0-1.8 2-5 3-6 1-2.1 1.4-2.4
60 psi 4 kg/cm 2 500 2000 5-54 2-4 2-4.5 1-2 1-2.5 3-7 4-8 1.4-2.8 1.4-3.5
200 psi 14 kg/cm 2 1000 4000 18-180 10-15 10-18 1.0-4.0 5.0-8.0 14-23 14-30 1.4-5.6 7.0-11.2
400 psi 28 kg/cm 2 1000 8000 45-360 16-30 16-45 4.0-8.0 5.0-15 22-42 22-63 5.6-11 7.0-21
NOTES:
1. Switches may generally be set between 15% and 100%
of nominal range on increasing or decreasing pressure.
Consult factory for applications where setpoints must be
lower.
2. All deadbands are given in English units as shown in
the nominal range column. Deadbands shown are for
switches with Buna N diaphragm.
Approximate deadbands for optional diaphragms:
Viton:
Multiply Buna N value by 1.4
Teflon: Multiply Buna N value by 1.2
Stainless Steel: Multiply Buna N value by 1.7
Monel: Multiply Buna N value by 1.7
3. Deadbands for LPA, LDA, GPA, and GDA are
adjustable between the values shown.
4. Deadbands for LPS, LPD, LDS, LDD, and GPS, GPD, GDS,
GDD models are fixed within the range of values shown.
5. Deadbands given are for zero static working pressure.
G and L PRESSURE RANGES
