Wilbur Curtis EXPR - Manual (Page 6)

6
1
2
5
6
3
4
Illustrated Parts – Main View
COVER, TOP
PANEL, LEFT SIDE EXPR
BRACE, LEFT SIDE
DOOR, COMPLETE
BRACE, RIGHT SIDE
PANEL, SIDE RIGHT
LAMP, 30W 5K CIRCULAR (BULB ONLY)
FILM, GENERIC EXPR
KIT, UCM & SMART CARD & OVERLAY
LABEL, UCM PANEL 1
2
3
4
5
6
7
8
9
10 WC-58222
WC-68191
WC-68175
WC-58232
WC-68174
WC-68192
CA-1123
CA-1143
WC-37298*
WC-39608
Item № Part № Description
CANISTER, ASSY ULTRA SLIM W/O SPRINGS
CANISTER ASSY, 10LB RIGHT PCGTs
LAMP COMPLETE, W/5K BULB (OLD UNITS)
LAMP, LED ASSY 11-12W 36VDC (NEW UNITS)
POWER SUPPLY, 120V - 36VDC (NEW UNITS)
ELBOW, PC/CK/HC
ELBOW, CANISTER RIGHT
ELBOW, CANISTER LEFT
MOTOR, WHIPPER
FITTING, BULKHEAD WATER 11*
12
13
13A
13B
14
15
16
17
18 CA-1142-07
CA-1113-06R
CA-1127 *
CA-1174
CA-1174-101
CA-1026-03
CA-1026-06
CA-1026-07
WC-3739 *
CA-1011-05
Item № Part № Description
* Suggested Parts to Stock
