Wilbur Curtis TCC1N User Manual
Page 5
5
1
2
3
4
5
6
7
8
9
10
11
12
13
26
15
16
17
18
19
25
24
23
29
30
30
22
20
21
1
1A
2
3
4
5
6
7
8
9
9A
9B
10
11
12
13
14
WC-56043
WC-5683
WC-53116
WC-8653
WC-38471
WC-1906
WC-4320
WC-1829
WC-1903
WC-5686
DT-06
DTP-08
WC-53113
WC- 894
WC-43084
WC-29069
WC-37288
LID,
TCC1N & TCC2N
LID, ASSEMBLY
TCC3N
TUBE, CLEAR BEV 3/8 SWEETEN SYSTEM
QCD, LIQUID BOX BAG CONNECTOR
LABEL, GENERIC TCO
C’ RING
O’ RING .487 ID X .103 CS
FAUCET, ASSY TCC BLK PLST
NUT, UNION SHANK
DRIP TRAY, OCTAGON STYLE
TCC1N
DRIP TRAY, 6 INCH
TCC2N
DRIP TRAY ASSEMBLY, PLASTIC
TCC3N
TUBING, .25 ID x .50 OD BRAIDED SLCN
VALVE, MIXING
O’ RING, .070” ID x .070W BUNA-N TCCs
ROD, ADJUSTABLE MIXING VALVE TCCs
KIT, CHECK VALVE AND INSTRUCTIONS
DESCRIPTION
PART Nº
ITEM Nº
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
WC- 810-102
WC-53114
WC-12011
WC- 811-101
WC- 569
WC-2451
WC-2452
WC-2445
WC-4279
WC-38466
WC-61634-102
WC-3531
WC-43002
WC-2219
WC-43137
WC-1433
VALVE, CHECK 3/8 X 3/8 BARBED NYLON
TUBING, .375” ID X .625” OD BRAIDED
VALVE, ANGLED STRAINER
REGULATOR, PRESSURE 1/4” 0-50 PSIG
GAUGE, REGULATOR 0-30 PSI
ADAPTER, 3/8 OD STEM X 1/4 NPTF
VALVE, CHECK 3/8 OD TUBE X 3/8 OD TUBE
STEM, 3/8 BARB X 3/8 STEM SWTNR SYS
NUT, 7/16-20 UNF-2B THREAD
LABEL, IMPORTANT WEEKLY CLEAN
COVER, BACK
LEG, PLASTIC GLIDE
CLAMP, HOSE SNAP NYLON .525/.605
Y-FITTING, BARB ¼ x ¼ x ¼ WHT
TCC2N/3N
BUSHING, SNAP .672” TCC’s
PLUG, DOME .875” HEYCO
DESCRIPTION
PART Nº
ITEM Nº
ILLUSTRATED PARTS LIST
TCC1N
All Parts Are Common
Except Where Noted
in Parts List
