Wilbur Curtis TCT with Sweet Tea Option - Manual (Page 9)

9
Illustrated Parts List - TCTS/T
PARTS LIST
* Recommended parts to stock
KIT, BREW CONE GOURMET PLASTIC FOR TEA UNITS
KIT, BREW CONE GOURMET PLASTIC (PARADISE TEA)
STRAINER BT-10 BREWCONE TEA UNITS
STRAINER, BREWCONE (PARADISE TEA)
BREWCONE ASSY, TEA W/STRAINER (OPTIONAL)
HANDLE, BREW CONE BLACK (FOR WC-33001-101)
WIRE BASKET, LARGE CAPACITY (OPTIONAL)
COVER, TOP BREWER
FITTING ASSY, SPRAYHEAD W/O-RING
UCM KIT, LABEL & OVERLAY 120V TCTS/T
LABEL, UCM OVERLAY TCT SWEET TEA CURTIS LOGO
LABEL, UCM OVERLAY SWEET W/HALF BATCH CURTIS
SPRAYHEAD, PURPLE ADVANCE FLOW
SPRAYHEAD, GRAY (OLDER UNITS)
SPOUT ASSY , DILUTION PLASTIC
SPOUT, BYPASS ASSEMBLY (OLDER UNITS)
HEAT SINK ASSY DV
KIT, DUAL VALVE WATER INLET
ELBOW, 3/8 NPT X 1/4 FLRE PLTD (OLDER UNITS)
COVER, FRONT TCTS
COVER, CENTER WRAP TCTS TCTDP-35S (OLDER UNIT)
COVER, CENTER WRAP TCTT/TCTD-35 (OLDER UNIT)
SWITCH, TOGGLE SPST 25A 125/250VAC RESISTIVE
LEG, GLIDE 3/8”-16 STUD SCREW
LEG, 8-32 STD SCREW BUMPER
RAIL, BASE TCTD
COVER, TOP HEATING TANK GEN USE
COVER, TANK W NOTCHES (MADE BEFORE 4/08)
GASKET, TANK LID
TANK ASSY, COMPLETE TEA BREWER
COMPOUND SILICONE 5 OZ
KIT, PROBE, WATER LEVEL W/FITTING, O-RING, & NUT
ELEMENT, HEATING 1.6KW 120V W/JAM NUTS
SHOCK GUARD, HEATING ELEMENT
SENSOR, TEMPERATURE TANK
THERMOSTAT, MANUAL RESET 120/240VAC 25A 220ºF
TUBING, 5/16” ID X 1/8” W SILICONE
LID ASSY, TCO
LABEL, FRONT TCO-308, TCO417, TCO419, TCO421
FAUCET, SPB
SEAT CUP, FAUCET S’
KIT, REPAIR SPB FAUCET
KIT, FAUCET W/ADAPTER COMPLETE
TEE, FLARE ¼ x ¼ x ⅜ BRASS
TUBE ASSY, FLEXIBLE 1/4 FLARE 11-1/8”
VALVE, INLET 1 GPM 120V 10W (OLDER UNITS)
VALVE, INLET DUAL 120V 10W 2 GPM X .5 GPM
VALVE, INLET BRASS .50 GPM 120V 10W (OLDER UNITS)
O’RING, .426 X 9/16 O.D X .070 WALL EDPM TCTS
DESCRIPTION PART Nº ITEM
1
1A
2
2A
3
4
5
6
7
8
9
9A
10
10A
11
11A
12
13
13A
14
14A
14B
15
16
16A
17
18
18A
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
37A
38
WC-37256
WC-37239
WC-3647
WC-8532
WC-33001-101
WC-3201
WC-3353
WC-58117
WC-2977-101
WC-37276*
WC-39600*
WC-39683
WC-29025*
WC-2942
WC-66079
WC-2965
WC-8556*
WC-37255
WC-2401
WC-58017-104
WC-58017
WC-58021
WC- 102*
WC-3518
WC-3503
WC-8531
WC-5853-102
WC-5851
WC-43062
WC-6277
WC-5231*
WC-5502-01*
WC- 904-04*
WC-4394
WC-1438-101*
WC- 523*
WC-5310*
WC-5683
WC-38471
WC-1803
WC-1805*
WC-3707*
WC-37260*
WC-2707
WC-53038
WC- 826L*
WC- 895-105*
WC- 801*
WC-43134
