Wilbur Curtis OMGT16 - Manual (Page 3)

3
Touch Screen Control Module
The touch screen turns on when power is available to the controller. The screen will
contain standard control feature such as symbols and buttons. Pressing these elements
with your finger tip will activate the programming functions. The default screen, as well
as some added control buttons, are shown in the illustration below.
ENTER
CURTIS LOGO
TO ENTER PROGRAMMING
Tap Curtis logo 5 times to bring
up the ACCESS CODE screen.
RETURN TO HOME SCROLL UNDO
CONTROL SYMBOLS
All of these symbols may not be
visible at one time.
STATUS LIGHTS
BREW
BUTTONS
MAIN MENU screen contains six control icons:
RECIPES, CONTROL SETTINGS, BREW SETTINGS,
MODEL SELECT, SETTINGS SUMMARY and EXIT.
ACCESS CODE screen. Default is 1 2 3 4.
Once the code is entered, press OK. The
Main Menu screen will appear.
The access code can be reset in Control
Settings, PASSWORDS.
PROGRAMMING
PROGRAMMING Continued . . .
