NVIDIA Quadro NVS 290 NVIDIA Quadro NVS 290 NVIDIA Quadro NVS 290 NVIDIA Quadro NVS 290
256MB PCIe Dual Head
256MB PCIe Dual Head 256MB PCIe Dual Head 256MB PCIe Dual Head
Form Factor Form Factor Form Factor Form Factor Low Profile
Bus Type Bus Type Bus Type Bus Type PCIe x16
Memory Memory Memory Memory 256 MB 400MHz DDR2 SDRAM unified frame buffer, Z-buffer and Texture
storage
Connector Connector Connector Connector DMS-59; includes one DMS-59 to Dual VGA cable. A DMS-59 to Dual DVI-
I cable is available as an option.
Display resolution support Display resolution support Display resolution support Display resolution support Dual integrated analog display controllers supporting up to two analog
displays at 2048x1536 @ 85Hz on both displays or dual digital displays at
1920x1200 (single-link).
NVIEW advanced multi-display desktop and application management
seamlessly integrated into Microsoft Windows
RAMDAC RAMDAC RAMDAC RAMDAC Integrated dual 400MHz
Color planes Color planes Color planes Color planes 32-bit color buffer
Overlay planes Overlay planes Overlay planes Overlay planes Hardware supported
nView architecture nView architecture nView architecture nView architecture Advanced multi-display desktop & application management seamlessly
integrated into Microsoft Windows.
Multi-Monitor support Multi-Monitor support Multi-Monitor support Multi-Monitor support Dual monitor support
DVI support DVI support DVI support DVI support DMS-59 (to dual DVI-SL)
High-definition Video High-definition Video High-definition Video High-definition Video
Processor
Processor Processor Processor (HDVP)
Full-screen, full-frame video playback of HDTV and DVD content
DVD-ready motion compensation for MPEG-2
Independent hardware color controls for video overlay
Hardware color-space conversion (YUV 4:2:2 and 4:2:0)
IDCT motion compensation
5-tap horizontal by 3-tap vertical filtering
8:1 up/down scaling
Supported graphics APIs Supported graphics APIs Supported graphics APIs Supported graphics APIs OGL 2.1 & DX10 Support; Shader Model 4.0
NVIDIA Quadro NVS 295 NVIDIA Quadro NVS 295 NVIDIA Quadro NVS 295 NVIDIA Quadro NVS 295
Graphics Card
Graphics Card Graphics Card Graphics Card
Form Factor Form Factor Form Factor Form Factor 2.731 inches (H) × 6.600 inches (L), Half-Height
Graphics Controller Graphics Controller Graphics Controller Graphics Controller NVIDIA Quadro NVS 295 Graphics Board
Bus Type Bus Type Bus Type Bus Type PCI Express x16, Generation 2.0
Memory Memory Memory Memory 256 MB GDDR3 SDRAM unified graphics memory
Connectors Connectors Connectors Connectors 2 DisplayPort
Comes with 2 DisplayPort to VGA Adapters
NOTE: NOTE: NOTE: NOTE: When purchased as an after-market option, this comes instead with
2 DisplayPort to DVI-D adapters.
Maximum Resolution Maximum Resolution Maximum Resolution Maximum Resolution Two DisplayPort outputs drive two digital displays up to 2560 x 1600
Display Output Display Output Display Output Display Output Drives DisplayPort enabled digital displays at resolutions up to 2560
× 1600 at 60 Hz with reduced blanking
Drives DVI enabled digital displays at resolutions up to 1920 × 1200
at 60 Hz with reduced blanking (through DisplayPort to DVI-D (single
link) cable)
Supported Graphics APIs Supported Graphics APIs Supported Graphics APIs Supported Graphics APIs OpenGL 3.0
DirectX 10.0
QuickSpecs
HP Compaq 8100 Elite PC HP Compaq 8100 Elite PC HP Compaq 8100 Elite PC HP Compaq 8100 Elite PC
Technical Specifications - Graphics
DA - 13524 Worldwide — Version 5 — February 3, 2010 Page 31
