Intel Gigabit CT Desktop Intel Gigabit CT Desktop Intel Gigabit CT Desktop Intel Gigabit CT Desktop
NIC
NIC NIC NIC
Connector Connector Connector Connector RJ-45
Controller Controller Controller Controller Intel 82574L Gigabit Ethernet Controller
Memory Memory Memory Memory 40KB configurable transmit/receive FIFO Buffers
Data rates supported Data rates supported Data rates supported Data rates supported 10/100/1000 Mbps
Compliance Compliance Compliance Compliance IEEE 802.1P, 802,1Q, 802.2, 802.3, 802.3AB and 802.3u compliant,
802.3x flow control, 802.1as Time synch offload
Bus architecture Bus architecture Bus architecture Bus architecture PCIe Base 1.1 (2.5 GT/s) x1
Data path width Data path width Data path width Data path width X1, 250 MB/s, Bi-directional interface
Data transfer mode Data transfer mode Data transfer mode Data transfer mode Bus-master DMA
Hardware certifications Hardware certifications Hardware certifications Hardware certifications (see EPS for more certification details)
EMI: FCC Class B
Intel 25-GS3000 Environmental Specification.
EN-55024: 1998 specification (see EPS for details)
EN-55022: Class A 1998 specification.
EN-60950-1 first Edition specification.
C-Tick specification, Class A
VCCI Class 1 specification.
CE specification and CE Mark.
UL 60950-1 first Edition specification.
CSA 60950-1 first Edition specification.
BSMI CNS13438 Class A specification
Korean MIC Class A specification.
European RoHS directive
China RoHS directive
Power requirement Power requirement Power requirement Power requirement 3.3V and 3.3V Aux, 2.1 Watts max in 1000Base-T (D0)
Boot ROM support Boot ROM support Boot ROM support Boot ROM support Yes
Network transfer rate Network transfer rate Network transfer rate Network transfer rate 10BASE-T (half-duplex) 10 Mbps
10BASE-T (full-duplex) 20 Mbps
100BASE-TX (half-duplex) 100 Mbps
100BASE-TX (full-duplex) 200 Mbps
1000BASE-T (full-duplex) 2000 Mbps (actual rate limited by PCI Bus)
Environmental Environmental Environmental Environmental Operating temperature Operating temperature Operating temperature Operating temperature 0 °C to 55 °C (operating)
-40 to 70 °C (non-operating)
Operating humidity Operating humidity Operating humidity Operating humidity 85% at 131° F (55° C)
Dimensions Dimensions Dimensions Dimensions Low-profile, half-length form factor conforming to PCIe * CEM v1.1 (55 mm
x 119 mm)
Management capabilities Management capabilities Management capabilities Management capabilities SMBus, WOL, PXE
HP Wireless 802.11b/g/n HP Wireless 802.11b/g/n HP Wireless 802.11b/g/n HP Wireless 802.11b/g/n
(PCIe)
(PCIe) (PCIe) (PCIe)
Dimensions Dimensions Dimensions Dimensions (L x H) 3.3 x 4.7 inches (8.5 x 12 cm)
Weight Weight Weight Weight 0.08 pounds (40 g)
Controller Controller Controller Controller Ralink RT2790
System interface System interface System interface System interface PCIExpress x1
Network standard Network standard Network standard Network standard 802.11 b/g/n
Frequency band Frequency band Frequency band Frequency band 2.400 - 2.497 GHz
QuickSpecs
HP Compaq 8100 Elite PC HP Compaq 8100 Elite PC HP Compaq 8100 Elite PC HP Compaq 8100 Elite PC
Technical Specifications - Communications
DA - 13524 Worldwide — Version 5 — February 3, 2010 Page 24
