Ryobi RMS10 - Manual (Page 7)

7
OPERATION
WARNING:
Do not allow familiarity with tools to make you care-
less. Remember that a careless fraction of a second is
sufficient to inflict serious injury.
WARNING:
Always wear eye protection with side shields marked to
comply with ANSI Z87.1. Failure to do so could result in
objects being thrown into your eyes, resulting in possible
serious injury.
WARNING:
Do not use any attachments or accessories not recom-
mended by the manufacturer of this tool. The use of at-
tachments or accessories not recommended can result
in serious personal injury.
WARNING:
This stand is designed for use with the TS1141 miter
saw only. Use with any other saw can result in serious
personal injury.
APPLICATIONS
You may use this tool for the following purpose:

To provide a stable, secure work surface for a miter
saw
USING THE EXTENSION RAILS
See Figure 6.
Use the extension rails when working with longer work-
pieces.
To extend the rails:

Loosen the extension adjustment knob.
 Depress the locking pin and extend the rail to the desired
position.
 Tighten the extension adjustment knob.
USING THE WORK SUPPORTS
See Figure 7.
Raise the work supports as needed so that longer workpieces
are level as they rest on the miter saw table.
To raise the work supports:

Loosen the work support adjustment knob.
 Raise the work support to the desired position.
 Tighten the work support adjustment knob.
Fig. 7
Fig. 6
extension
rail
work support
adjustment
knob
adjustment
knob
loCkinG pin
