Figure 3-1 – Cisco 6901 User Manual
Page 5
3-5
Cisco Unified IP Phone 6901 and 6911 Administration Guide for Cisco Unified Communications Manager 8.0 (SCCP)
OL-20852-01
Chapter 3 Setting Up the Cisco Unified IP Phone
Installing the Cisco Unified IP Phone
Figure 3-1
Cisco Unified IP Phone 6901 Cable Connections
4
5
6
1
2
3
195792
1
Slot for Ethernet cable
4
Network port (10/100 SW) connection
IEEE 802.3af power enabled
2
Handset connection
5
DC adaptor port (DC48V)
3
Slot for handset cable
6
Slot for DC adaptor cable
