SHEET METAL SCREW
#6 X1/2” LONG
6 REQUIRED
PARTS LIST AND HARDWARE
4
5/16 ID X 11/16" OD STEEL FLAT WASHER
6 REQUIRED
8mm x 16 mm PHILLIPS HEAD
6 REQUIRED
5/16 X 2 1/2 LAG BOLT
6 REQUIRED
5/16 X 7/8 USS STEEL
FLAT WASHER
6 REQUIRED
CARLON VOLTAGE BOX
CARLON-B114R
2 REQUIRED
IN WALL BOX
1 REQUIRED TRIM PLATE
1 REQUIRED
1 2
5
4
7
8
6
3
(Box can be used with standard covers, receptacles and plates)
