Mounting points for panel display models
Mounting bracket
A
B
J
H C
I
K
G
5 mm x 16 mm Phillip screws…4 pcs
6 mm x 40mm Philips screws...4pcs
8 mm x 40mm Philip screws...4 pcs
Plastic spacer...4 pcs
Display bracket .... 2 pcs
E
D
6 mm x 16 mm Phillip screws…4 pcs
8 mm x 16mm Philip screw...4 pcs
F
32”
Panel Display mounting points
20”
Fig 1
PARTS LIST FOR PDM110 T HN
Top
Bottom
Square multi-mount washers...4 pcs
L
5 mm x 40 mm Phillip screws...4 pcs
4 mm steel flat washer... 4 pcs 4 mm x 16 phillips screw... 4pcs
Three position height adjustment
(Attached to AWM 175)
PDM -0060 HARDWARE KIT
PDM -0062 HARDWARE KIT
