Metalfab Industrial Electric Vibrator - Manual (Page 9)

Metalfab, Inc. M3258-09/08
5
Electric Vibrators
Figure 5. Wiring Connection Diagrams: UL/cUL/ATEX Approved CDX Series
Division 1 Class I Groups C and D, Class II Groups E, F, and G;
EExd IIB T4
Figure 6. Manual Reset Connections
P1
P2
W2 U2 V2
U1 V1
W1
P1
P2
W2 U2 V2
U1 V1
W1
Cable Entry
High Voltage Low Voltage
9700K Thermostat Connection Diagram to Terminal Board
G G
Stop
Start
1
2
3
Motor
Motor
Windings
P1
P2
Starter
Overload
Contacts Starter
Coil
W
V
U
Motor Starter
Lin
e
