Metalfab Industrial Electric Vibrator - Manual (Page 21)

Metalfab, Inc. M3258-09/08
17
Electric Vibrators
Figure 10. Frame Sizes 30, 40, 50 Vibrator Parts Drawing
* Part Not Shown in Drawing
Vibrator
Frame Size and Part Number (Model Number)
30 40 50
Description Item
601149
(CDX18-2100)
601150
(CDX18-3500)
601217
(CD18-3190)
601227
(CD18-2000)
601219
(CD18-3870)
601358
(CDX18-4400-D)
Case 1 300177 300178 300236 300236 300236 300436
Flange 3 301148 301149 301196 301196 301197 301254
Screw 4 515507 515593 515508 515508 515508 515508
Washer, Schnorr 5 513004 513004 513004 513004 513004 513004
O-Ring 6 508560 508588
Shaft 7 400214 400215 400286 400286 400287 400367
Bushing, Shaft 9 508049 508049 508049
Bearing 10 506531 506547 506535 506535 506538 506538
Key 13 506029 506044 506044 506044 506044 506044
Weight, Fixed 50 Hz 14 304246 304250 517658 517660 517665
Weight, Fixed 60 Hz 14 304247 304251 517660 517663 517667 517658
Weight, Adj 50 Hz 15 305167 305171 517659 517661 517666
Weight, Adj 60 Hz 15 305168 305172 517661 517664 517668 517659
Screw 16 516556 516544 515559 515559 515559 515559
Washer, Schnorr 17 513004 513004 513005 513005 513005 513005
Washer, Brass* 18 513514 513514
Disc, Weight Adj 50 Hz 19 518156/7 518174/5
Disc, Weight Adj 60 Hz 19 518156/7 518174/5
Ring, Snap 20 500041 500058 500055 500055 500055 500055
Nut, Hex 21 509070 509070 509070 509070
O-Ring 22 508576 508621 508621 508621 508621 508601
Cover, Weight 23 306076 306077 517076 517076 517055 306129
Screw 24 515505 515506 515508 515508 515508 515508
Washer, Schnorr 25 513003 513003 513004 513004 513004 513004
Terminal Block 26 510501 510501 510501 510501 510501 510501
Terminal Block U.S. 26 510501 510501 510501 510501 510501 510501
Screw 27 515501 515501 515502 515502 515502 515501
Washer, Schnorr 28 513002 513002 513002 513002 513002 513002
Screw, Ground 29 516555 516555 515533 515533 515533 516555
Washer, Schnorr 30 513003 513003 513002 513002 513002 513003
Tag, Ground 31 518407 518407 518025 518025 518025 518407
Block, Rubber 32 514021 514021 514041 514041 514041 514039
O-Ring 33 508620 508620 508612 508612 508612 508671
Cover, Wiring Box 34 309031 309031 502500 502500 502500 309037
Screw 35 515509 515509 515611 515611 515611 515538
Washer, Schnorr 36 513004 513004 513003 513003 513003 513005
Fitting, Cord 37 511579 511579 511579
Fitting, Grease 38 509050 510000 510000 510000
Protector, Lead 39 514022 514022 514023 514023 514023 514031
Ring, Snap 40 500015 500015 500015
Cover, Bearing 46 303048 502801 502801 502801 303080
Screw/Ring Snap* 47 515505 500076
Washer Schnorr* 48 513003
Thermostat Term. Block 49 510510 510510 510510
Screw, Terminal Block 50 515605 515605 515605
Screw Insert 51 509056 509056 509056
