Vibrator Force Adjustment

WARNING! Before any adjustments, vibrator should be electrically

ÅgLOCKED OUTÅh.

1. The centrifugal force setting of the vibrator is set at the factory for the

minimum force level that will produce flow of product. If flow is not

instantaneous or continuous, it may be necessary to increase the centrifugal
force. To do so, the following procedure should be followed:

1) Remove the bolts of both the upper and lower end covers.

2) Remove the covers exposing the four (4) eccentric weights.

2. To increase the force setting, loosen the clamping bolt on the two (2) weights

that will be adjusted. (See note above).

3. Refer to the applicable vibrator operation and maintenance instructions for

force settings and technical information.

4. As the centerline of the adjusted weights approach the centerline of the fixed

weights, the centrifugal force is increased. When the weights centerline are

opposed, the centrifugal force decreases. If the centerline of all four (4)
weights are completely aligned, you will develop the maximum force available

for that size vibrator.

5. Regardless of which vibrator you have, when you have completed your force

adjustment, the OUTER weights should be in line with each other and the
INNER weights should be in line with each other. ANY OTHER

ARRANGEMENT WILL RESULT IN A MOTION THAT CAN DAMAGE THE
VIBRATOR AND BE VERY DETRIMENTAL TO THE APPLICATION, WELDS OF

THE BIN ACTIVATOR AND SUPPORT STRUCTURES.

6. Assemble the unit by reversing the procedure outline as above.

Note:

Bin Activator vibrator should be electrically interlocked

with down stream feed devices, i.e., when screw, belt,

rotary, etc., feeder stops _ vibrator should also stop.

Full Load and Starting Current

See Vibrator Instruction Manual and Motor Nameplate Data.
