Page 26
— 24 —
ESC & s n m [a [p] s
×
a] m–n+1
[Function]
Defining the download characters
[Code]
⋅ ⋅
× a>]m-n+1 [Range] s = 3 32 n m 126 0 a 12 (Font A) 0 a 9 (Font B) 0 p1 ⋅ ⋅ ps × a 255 [Outline] Defines the font of download characters of alphanumeric • “s” indicates the number of bytes in vertical direction. • “n” indicates the start character code and “m” the end character code. To define only one character, set n=m. • Character codes definable includes 95 ASCII codes in total in the range of <20>H to <7E>H. • “a” indicates the number of dots to be defined in horizontal direction. • “p” is the data to be defined, which indicate a pattern equal to “a” dots in horizontal direction from the left end. The rest of The number of data to be defined is s × a. • Download characters thus defined remain valid until redefinition, ESC @, GS * , FS q execution, ESC ? deletion or power OFF is performed. [Caution] • Download characters and download bit images cannot be defined simultaneously. • Running this command clears the definition of the download bit image. [Default] Same as the internal character set. [See Also] ESC %, ESC ?
characters.
the pattern on the right side is filled with space.
