19
You can set the flash output from 1/64 power to 1/1 full power in 1/3-
stop increments.
Use a hand-held flash meter to determine the required flash output to
obtain a correct flash exposure. Setting the camera’s shooting mode to
or is recommended.
1 Press the <D> button so
that <q> is displayed.
2 Set the flash output.
Press the <8> button.
X The flash output blinks.
Press the <9> button to set the
flash output, then press the <8>
button.
Press the shutter button halfway to
see the effective flash range
displayed.
The manual flash output value will change as shown below when the
flash output is decreased or increased.
q : Manual Flash
Flash Output Display
(Example) Figures for decreased flash output →
1/1
1/1 -0.3 1/1 -0.7
1/2
1/2 -0.3 1/2 -0.7
1/4
•••
1/2 +0.7 1/2 +0.3 1/4 +0.7 1/4 +0.3 •••
← Figures for increased flash output
