23
Thermostat Adjustment Continued-
Figure 11
The thermostat dial is set to its lowest temperature setting when shipped from
the factory. Remember that lower temperature settings are more energy
efficient
. Adjust the temperature by turning the thermostat dial. It is
suggested that the starting point setting not be greater than the ” “ mark on
the thermostat dial (approximately 120°F [48.9°C]) as pictured above. Rotate
the thermostat dial clockwise
to decrease the temperature setting.
Rotate the thermostat dial counter-clockwise to increase the
temperature setting. Adjust the dial until the minimum acceptable temperature
is achieved (See Figure 11 above for approximate temperature settings).
GAS CONTROL
KNOB
GAS
REGULATOR APPROXIMATELY
120°F (48.9°C)
APPROXIMATELY
85°F (71.1°C)
APPROXIMATELY
160°F (48.9°C)
TERMOSTAT
TEMP. DIAL
