Bradford White M-I-MS40T6LX - Manual (Page 22)

22
Thermostat Adjustment
Figure 9
The thermostat dial is set to its lowest temperature setting when shipped from
the factory. Remember that lower temperature settings are more energy
efficient
. Adjust the temperature by turning the thermostat dial. It is
suggested that the starting point setting not be greater than the ” “ mark on
the thermostat dial (approximately 120°F [48.9°C]) as pictured above. Rotate
the thermostat dial clockwise
to decrease the temperature setting.
Rotate the thermostat dial counter-clockwise to increase the
temperature setting. Adjust the dial until the minimum acceptable temperature
is achieved (See Figure 9 above for approximate temperature settings).
Figure 10
The thermostat dial is set to its lowest temperature setting when shipped from
the factory. Remember that lower temperature settings are more energy
efficient
. Adjust the temperature by turning the thermostat dial. It is
suggested that the starting point setting not be greater than the “ ” mark on the
thermostat dial (approximately 120°F [48.9°C]) as pictured above. Rotate the
thermostat dial counter-clockwise
to decrease the temperature
setting. Rotate the thermostat dial clockwise to increase the
temperature setting. Adjust the dial until the minimum acceptable temperature
is achieved (See Figure 10 above for approximate temperature settings).
