Installation (Horizontal and Vertical Vent-Air Intake Lengths) continued-

The following components are found in the standard vent and air intake kit,
P/N 239-42979-00 (kit H). This kit, as well as all optional vent and air intake
kits must be ordered separately from the manufacturer shown on the rating
plate.

4” Vent Tube*

Vent Terminal Hardware

6” Air Intake Tube

RTV Silicone Sealant

Vent Terminal

4” Vent Elbow

Inner Wall Term. Mounting Flange

6” Air Intake Elbow

Outer Wall Term. Mounting Flange

• The vent and air intake telescopes from 13 3/4” to 23 11/16”.

Table A

Horizontal

"X"

16 1/4

18

25 1/4

37 3/4

61 5/16

17 3/16

20 11/16

35 3/16

57 7/8

107 5/16

order

order

no add'l

order

order

11 9/16

kit F

kit G

kit req'd

kit H

kit I

16 5/16

*order

order

order

order

order

17 1/4

kit F (2)

kit G & F

kit F

kit H & F

kit F & I

18 1/16

order

order

order

order

order

20 3/4

kit F & G

kit G (2)

kit G

kit G & H kit G & I

25 5/16

order

order

order

order

order

35 1/4

kit F

kit G

kit H

kit H (2)

kit I

38 1/16

order

order

order

order

order

57 15/16 kit H & F kit H & G kit H (2)

kit H (3)

kit H & I

61 3/8

order

order

order

order

order

Vertical "Y"

107 3/8

kit I & F

kit I & G

kit I

kit I & H

kit I (2)

* (2) = Order two of the kits referenced.
* (3) = Order three of the kits referenced.

The bold text above show what kit(s) are needed in addition to the standard
vent and air intake tubes. If the standard vent and air intake tubes are not
used in the venting system (those that do not have bold text) they can be
discarded or saved.
