PARTS LIST DRAWING
PARTS LIST
PART NAME AND DESCRIPTION
1. Blower Assembly 11. Diptube – Nipple
2. Temperature Switch 12. Anode – Nipple
3. Pressure Switch 13. Thermostat (Behind Cover)
4. Flue Baffle 14. T & P Relief Valve Opening
5. Honeywell Smart Valve 15. Pilot Assembly
6. Drain Valve 16. Cast Iron Burner
7. Fiberglass Insulation 17. Main Burner Orifice
8. Foam Insulation 18. Gas Feedline
9. Outer Door 19. Air Shutter (Cast Iron Only)
10. Thermostat Cover 20. Steel Burner
