17

Installation (Venting (Part I)) continued-

TABLE 4

3” (7.6 cm) PVC VENT CONNECTOR LENGTHS FROM INSIDE WALL

FOR LOW GROUND CLEARANCE INSTALLATIONS

Terminating #

of

Elbows

Maximum
Length

Minimum
Length

(2) 90

° Elbows with (1) 90° Elbow

1 30

ft

(9.1 m) 5

ft

(1.5 m)

(2) 90

° Elbows with (1) 90° Elbow

2 25

ft

(7.6 m) 6

ft

(2 m)

(2) 90

° Elbows with (1) 90° Elbow

3 20

ft

(6.1 m) 8

ft

(2.5 m)

(2) 90

° Elbows with (1) 90° Elbow

4 15

ft

(4.6 m) 10

ft

(3 m)

TABLE 5

4” (10.1 cm) VENT CONNECTOR LENGTHS FROM INSIDE WALL FOR

LOW GROUND CLEARANCE INSTALLATIONS

Terminating (Reduce 4” to 3”)

(Reduce 10.1 cm to 7.6 cm)

#of
Elbows

Maximum
Length

Minimum
Length

(2) 90

° Elbows with (1) 90° Elbow

1 60

ft

(18.3 m) 10

ft

(3 m)

(2) 90

° Elbows with (1) 90° Elbow

2 55

ft

(16.8 m) 12

ft

(3.7 m)

(2) 90

° Elbows with (1) 90° Elbow

3 50

ft

(15.2 m) 15

ft

(4.6 m)

(2) 90

° Elbows with (1) 90° Elbow

4 45

ft

(13.7 m) 18

ft

(5.5 m)

(2) 90

° Elbows with (1) 90° Elbow

5 40

ft

(12.2 m) 22

ft

(6.7 m)


HIGH ALTITUDE INSTALLATIONS FOR ELEVATIONS OVER 3,000
FEET (914.5 m)
ABOVE SEA LEVEL

The capacity of the induced draft blower declines with increasing altitude due to
a reduction in the air density. In order to assure safe and reliable performance
of the water heater, the following guidelines must be followed. Refer to the
venting tables below for maximum distances for the altitudes in your location.

TABLE 6 - HIGH ALTITUDE LENGTHS

Altitude above
sea level

Maximum
venting length
reduction
from tables 2
& 4

Maximum
venting length
reduction from
tables 3 & 5

Modifications to
water heater

0-3,000 ft
(0-914.5m)

No reduction in
vent length
required

No reduction in
vent length
required

None

over 3,000-
10,000 ft
(914.5-3048m)

No reduction in
vent length
required

No reduction in
vent length
required

Requires high
altitude kit. Call
the supplier or the
manufacturer
