INSTALLATION PROCEDURES
Installation in a proper location should be performed by competent technicians in accordance
with local and state codes.
A. REASSEMBLY OF DRYER
IMPORTANT: Always keep the basket (tumbler) section of the dryer
in an upright position when moving it.
The dryer can be shipped in two (2) ways: as a complete unit fully assembled and ready for
hookup or in two (2) pieces with the middle frame separated from the base. At installation,
the middle frame will be lifted onto the base. Use cables through the eye bolts on top of the
middle frame for lifting. Fasten the middle frame to the base by using the bolts. Also,
reconnect the V-belts, belt guard at the rear of the unit, and reconnect the electrical plugs
located in the front control boxes.
If the steam coil and damper piston removed, lift the steam connection pipes facing the right
side of the unit, and bolt the coil to the top of the middle frame using the #3/8-16 bolts. Also,
bolt the damper piston and solenoid valve to the top of the middle frame using the bolts
provided. There are three (3) panels that cover the front, right side, and rear of the steam
coil. Fasten these panels in position.
1. Reconnect the four (4) pin / socket connectors at the bottom of the right control box.
2. Reconnect the three (3) pin / socket connectors at the bottom of the left control box.
3. Reconnect the two (2) pin / socket connectors within the left control box.
4. Rewire the drive motor by inserting the three (3) black wires into the T1, T2, and T3
connections of the soft start.
5. Rewire the blower (impellor/fan) motor by inserting the three (3) blue wires into the T1,
T2 and T3 connections of the telemecanique blower contactor.
